Avtor: Vladka Salapura[1], Irena Zupan[2], Bostjan Seruga[3], Gorana Gasljevic[4], Pavel Kavcic [5]
1 Clinical Radiology Institute, UMC Ljubljana, Ljubljana, Slovenia
2 Clinical Department of Haematology, UMC Ljubljana, Ljubljana, Slovenia
3 Sector of Medical Oncology, Institute of Oncology Ljubljana, Ljubljana, Slovenia
4 Department of Pathology, Institute of Oncology Ljubljana, Ljubljana, Slovenia
Radiol Oncol 2014; 48(3): 243-246.
Received 7. March 2013
Accepted 12 May 2013
Correspondence to: Vladka Salapura, M.D., Ph.D., Clinical Radiology Institute, UMC Ljubljana, Zaloška 7, 1000 Ljubljana, Slovenia.
Phone: +386 41 33 66 97; E-mail: salapura@siol.net
Disclosure: No potential conflicts of interest were disclosed.
Background. RCC accounts for only 2–3% of all cancers. Due to its’ non-specific symptoms disease is often diagnosed in advanced stage. Disseminated RCC frequently produces bone metastases that are almost always highlydestructive, hyper vascularized and purely osteolytic.
Case report. In this article we describe a case of a 71-year old male patient with disseminated osteoblastic bone metastases from renal cell carcinoma (RCC), and present a short review of published literature reporting cases of osteoblastic bone metastases from RCC. Our patient presented with thoracic pain aggravated by movement. He was diagnosed with predominantly osteoblastic bone metastases in the skeleton of thoracic and lumbar vertebra along with metastases in iliac bones, ribs, humerus and clavicles. Initially, origin of bone metastases was unknown, but later a small tumor in patient’s right kidney was identified. Microscopic evaluation of the open bone biopsy showed clear cell RCC with sarcomatoid differentiation.
Conclusions. Although, due to its’ rarity, RCC is not included in the primary differential diagnosis in patients with osteoblastic metastases, such rare cases suggest that RCC may be considered in the diagnosis when there no other primary tumor is found.
Key words: renal cell carcinoma; osteoblastic bone metastases
Introduction
Renal cell carcinoma (RCC) accounts for 2–3% of all cancers.1 Due to non-specific symptoms disease is often diagnosed relatively late. Approximately one third of patients with newly diagnosed RCC already have metastatic disease.2 Metastases to the bones are frequent and occur in 35% to 40% of cases with advanced RCCs.3 Usually, these metastases are highly destructive, hypervascular and osteolytic.3 In a series of 1668 patients with RCC all detected bone metastases were exclusively osteolytic prior to the initiation of therapy.4 It is well known that specific therapies, such as radiotherapy may induce sclerotic changes in osteolytic bone lesions.
To our knowledge there are only six cases of patients with osteoblastic metastases from RCC reported in the literature: two involving well differentiated RCC5,6; two involving RCC with sarcomatoid differentiation7,8; one mixed clear cell with oncocytic features8 and one unclassified type.8 In
this article we represent a case of osteoblastic bone metastases from clear cell RCC with sarcomatoid differentiation.
Case report
FIGURE 1. A. CT scan shows osteoblastic metastasis in the anterior part of thoracic vertebral body (arrow); B. PET-scan shows that the lesion is metabolically active (arrow)
71-year old male was admitted to emergency department due to a chest pain that was aggravated by moving or breathing. Patient also had unexplained weight loss of 22 kg in the last 3 months. Medical history included arterial hypertension, diabetes and chronic kidney disease. Laboratory data showed normocytic anemia, elevated inflammatory parameters, elevated alkaline phosphatase and creatinine. Chest X-ray did not show any abnormalities. Initially, pulmonary embolisms were suspected, but chest computer tomography angiography (CTA) did not show any abnormalities in the lungs. Abdominal ultrasound examination found already known adrenal adenoma with no other abnormalities. As attending physician was suspicious of malignant disease patient was hospitalized. During hospitalization 18F-fluorodeoxyglucose PET/CT imaging was done which revealed disseminated predominantly osteoblastic metastatic lesions in thoracic (Figure 1) and lumbar spine (Figure 2), iliac bones (Figure 3), ribs, humerus and clavicles.
However, primary tumor was not identified initially. For further characterization magnetic resonance imaging (MRI) was planned, but unfortunately it was contraindicated due to more than 20 years old osteosynthetic material present in the lumbar vertebra. A CT guided biopsy of small osteoblastic lesion in the iliac crest was ordered. Unfortunately, biopsy was inconclusive, since it showed only a fatty bone marrow without any malignant cells. Finally, patient underwent an open bone biopsy of large osteoblastic lesion in the eleventh thoracic vertebra. Microscopic evaluation of the open biopsy showed clear cell RCC with sarcomatoid differentiation (Figure 4).
FIGURE 2. A and C. CT scan shows osteoblastic metastases in lumbar vertebral bodies (arrows); B and D. the same lesions show metabolic activity on PET-scan (arrows).
Afterwards patient was presented to medical oncologist. Control CT scan confirmed a small carcinoma in the right kidney (Figure 5) with diffuse bone metastases, which were predominantly osteoblastic. Additionally, numerous new tiny lung metastases were found leaving no suspicion that primary tumor was not in the lungs. His prostate specific antigen was 0.3 ng/ml and therefore it was very unlikely that osteoblastic metastases were from prostate cancer. At presentation patient had several poor-prognosis risk factors (WHO performance status 2-3, anemia and time from initial diagnosis to the start of treatment less than 1 year), which indicated short life expectancy. He was offered treatment with mammalian target of rapamycic (mTOR) inhibitor temsirolimus. Unfortunately, despite treatment with temsirolimus patient gradually deteriorated and after two months of treatment CT scan showed progression of disease in his lungs. Few weeks later patient died.
FIGURE 3. A. CT scan shows multiple osteoblastic metastases in the right iliac bone (arrow); B. PET-scan confirms these lesions to be metabolically active metastatic lesions (arrow)
FIGURE 3. A. CT scan shows multiple osteoblastic metastases in the right iliac bone (arrow); B. PET-scan confirms these lesions to be metabolically active metastatic lesions (arrow)
FIGURE 4. A. Metastasis of the RCC in the bone: cells with copious clear cytoplasm and nuclei with prominent, eosinophilic nucleoli; bone trabecule is in the bottom part of the field; H&E 40x; B. More spindled tumor cells, »sacomatoid« differentiation; H&E, 40x; C. Positivity for CAM5.2; IHC CAM5.2, 20x; D. Positivity for RCC; IHC RCC, 40x; E. Positivity for PAX8, IHC PAX8, 20x; F. Positivity for Vimentin; IHC Vimentin, 40x.
Discussion
The most common cancer types that metastasize to the bones are prostate, breast, lung cancer and RCC.9 When osteoblastic bone metastases are found in an adult male patient the most likely origin of malignancy is prostate cancer. However, when osteoblastic bone metastases are found in conjunction with an enhancing renal mass, the more likely pathology is urothelial carcinoma. Urothelial carcinoma such as transitional cell carcinoma commonly metastasizes to bones and can produce both osteolytic and osteoblastic metastases.10 RCC almost always produces osteolytic metastases and is therefore usuaally not considered in the differential diagnosis of osteoblastic metastases. However, advanced RCC can present with osteoblastic metastases as was also found in our case. RCC is made up of a number of different histological subtypes and each is caused by alterations of different genes. The common sites of metastases are lung, liver, bones, adrenals and lymph nodes.11 Some RCCs are associated with unfavorable histological features such as sarcomatoid differentiation, which indicate aggressive behavior. Our and two previously published case reports8,9 of patients with osteoblastic bone metastases from RCC reported sarcomatoid differentiation in bone metastases. This shows that sarcomatoid differentiation in bone metastases from RCC can be associated with osteoblastic metastases. Patients with metastatic RCC of bone have expected median survival of around 12 months; survival of those with sarcomatoid differentiation can be even worse.12,13 Now, the outlook is changing thanks to the advancements in targeted molecular therapy and cytoreductive nephrectomy.11 RCC is an immunogenic tumor that has ability to manipulate and suppress the natural immune system. The primary tumor might suppress the antitumor effect of the host defense mechanism and divert the immune cells away from the distant metastases.14
FIGURE 5. Abdominal CT scan shows small primary renal tumor in the the right kidney (contrast enchanced CT was not performed due to patient’s poor renal function with glomerular filtration less then 30 mL/min/1.73 m2).
Hence, removal of primary tumor (cytoreductive nephrectomy) together with additional immunotherapy can augment the host immune system thereby producing better survival and quality of life.11 New imaging techniques are also being developed. A recent study presented the first clinical validation of a molecular imaging biomarker for malignancy. It was shown that highly malignant clear cell RCC can be identified using (124) I-girentuximab PET/CT imaging with high sensitivity and specificity.15 With the progression in diagnostics, surgery, new radiotherapy techniques and the discovery of the new biological therapies which are more effective and less toxic, major changes of the therapeutic results are expected. In spite of this, RCC still remains a big challenge for the future research.16
Conclusions
In this article we presented a rare case of RCC with predominantly osteoblastic metastases. Although, due to its’ rarity, RCC is not included in the primary differential diagnosis in patients with osteoblastic metastases, such rare cases suggest that RCC may be considered in the diagnosis when there no other primary tumor is found. Especially, as survival of patients with metastatic RCC continues to increase due to new therapies, we may begin to see unusual radiologic characteristics of metastases, (such as osteoblastic metastases) more often. Ongoing research in treatment and imaging will help to optimize management of metastatic RCC in the future.
Osteoblastic bone metastases from renal cell ( .pdf datoteka)
References
- McLaughlin JK, Lipworth L. Epidemiologic aspects of renal cell cancer. Semin Oncol 2000; 27: 115-23.
- Patard JJ, Kim HL, Lam JS, Dorey FJ, Pantuck AJ, Zisman A, et al. Use of the University of California Los Angeles integrated staging system to predict survival in renal cell carcinoma: an international multicenter study. J Clin Oncol 2004; 22: 3316-22.
- Lin PP, Mirza AN, Lewis VO, Cannon CP, Tu SM, Tannir NM, et al. Patientsurvival after surgery for osseous metastases from renal cell carcinoma. JBone Joint Surg Am 2007; 89: 1794-1801.
- Forbes GS, McLeod RA, Hattery RR. Radiographic manifestations of bone metastases from renal carcinoma. AJR Am J Roentgenol 1977; 129: 61-6.
- Reidy JF. Osteoblastic metastases from a hypernephroma. Br J Radiol 1975;48: 225-7.
- Neugut AI, Casper ES, Godwin TA, Smith J. Osteoblastic metastases in renalcell carcinoma. Br J Radiol 1981; 54: 1002-4.
- Liu PT, Conley CR, Callstrom MR. Sclerotic bone metastases from sarcomatoid renal cell carcinoma. Skeletal Radiol 1999; 28: 590.
- Sneag DB, Krajewski KM, Howard S, Jagannathan JP, Star KV, Ramaiya N.Sclerotic osseous metastases from renal cell carcinoma. Skeletal Radiol2012; 41: 1169-75.
- Coleman RE. Metastatic bone disease: clinical features, pathophysiologyand treatment strategies. Cancer Treat Rev 2001; 27: 165-76.
- Shinagare AB, Fennessy FM, Ramaiya NH, Jagannathan JP, Taplin ME, vanden Abbeele AD. Urothelial cancers of the upper urinary tract: metastatic pattern and its correlation with tumor histopathology and location. JComput Assist Tomogr 2011; 35: 217-22.
- Bhat S. Role of surgery in advanced/metastatic renal cell carcinoma. IndianJ Urol 2010; 26: 167-76.
- Toyoda Y, Shinohara N, Harabayashi T, Abe T, Akino T, Sazawa A et al. Survivaland prognostic classification of patients with metastatic renal cell carcinomaof bone. Eur Urol 2007; 52: 163-8.
- Keegan KA, Schupp CW, Chamie K, Hellenthal NJ, Evans CP, Koppie TM.Histopathology of surgically treated renal cell carcinoma: survival differences by subtype and stage. J Urol 2012; 188: 391-7.
- Rosenberg SA, Yang JC, White DE. Durability of complete response in patients with metastatic cancer treatment with high dose IL2 identification ofthe antigen mediating response. Ann Surg 1998; 229: 307-19.
- Divgi CR, Uzzo RG, Gatsonis C, Bartz R, Treutner S, Yu JQ, et al. Positron emission tomography/computed tomography identification of clear cell renalcell carcinoma: results from the REDECT trial. J Clin Oncol 2013; 31: 187-94.
- Rajer M. Kidney cancer. Radiol Oncol 2007; 41: 64-71.
